Dahua 8MP IR Dome WizMind Network Camera (DH-IPC-HDBW5842HP-ZHE)
*HARGA HUBUNGI KAMI
Camera |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Sensor | 1/1.8” 8Megapixel progressive CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Resolution | 3840 (H) × 2160 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ROM | 4 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| RAM | 2 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Min. Illumination | 0.003 [email protected] (Color, 30IRE)
0.0003 [email protected] (B/W, 30IRE) 0 Lux (Illuminator on) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| S/N Ratio | > 56 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illumination Distance | 40 m (131.23 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator On/Off Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Illuminator Number | 3 (IR LED) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pan/Tilt/Rotation Range | Pan: 0°–355°
Tilt: 0°–80° Rotation: 0°–355° |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lens Type | Motorized vari-focal | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mount Type | Module interface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Focal Length | 2.7 mm-12 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Aperture | F1.2 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Field of View | Horizontal: 114°(W)–47°(T)
Vertical: 59°(W)–27°(T) Diagonal: 141° (W–55°(T) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Iris Type | Auto | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Close Focus Distance | w: 1 m (W: 3.28 ft)
T: 2.5 m (T: 8.20 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify | ||||||||||||||||||||||||||||||||||||||||||||||||||||||
| W | 87.2 m
(286.09 ft) |
34.9 m
(144.50 ft) |
17.4 m
(57.08 ft) |
8.7 m
(28.54 ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| T | 186.7 m
(612.53 ft) |
74.7 m (245.08 ft) | 37.3 m
(122.37 ft) |
18.6 m
(61.02 ft) |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart event |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| IVS | Abandoned object, moving object | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Professional, intelligent |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| IVS (Perimeter Protection) | Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Face Detection | Face detection, track, priority, snapshot;
Upload Optimized snapshot picture; Face enhancement, face exposure, face attribute extract,6 attributes and 8 expressions: Gender, age, glasses,expressions (anger, sadness, disgust, fear, surprise,calm, happiness and confusion), Mouth mask, beard; Face matting setting: face, single inch photo; Three snapshot methods: real-time snapshot, priority snapshot, quality priority; Face angle filter Priority time setting; Support Duration Optimal. |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| People Counting | Support tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports.Support queue management, and displaying and outputting monthly/daily reports.Support 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Compression | H.265, H.264, H.264H, H.264B, MJPEG(only supported by sub stream) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Smart Codec | Smart H.265+/ Smart H.264+ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Frame Rate | Main Stream: 3840 × 2160 (1–25/30 fps)
Sub stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) Third stream: 1920 × 1080 (1–25/30 fps) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Stream Capability | 3 streams | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Resolution | 8M (3840 × 2160)/6M (3072 × 2048/3072 × 1728)/5M (2592 × 1944)/4M (2688 × 1520)/3M (2048 × 1536/2304 × 1296)/1080p(1920 × 1080)/1.3M (1280 × 960)/720p(1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Video Bit Rate | H.264: 32 Kbps–16384 Kbps
H.265: 12 Kbps–16384 Kbps |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Day/Night | Auto (ICR)/Color/B/W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| BLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| HLC | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| WDR | 120 dB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Scene Self-adaptation (SSA) | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gain Control | Auto/Manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Noise Reduction | 3D NR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Motion Detection | OFF/ON (4 areas, rectangular) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Region of Interest(RoI) | Yes (4 areas) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Electronic Image Stabilization(EIS) | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Smart Illumination | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Defog | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution or below.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mirror | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Privacy Masking | 4 areas | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Compression | G.711a; G.711Mu; G726; G.723 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception, Queue Management | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Network | RJ-45 (10/100 Base-T) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SDK and API | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Protocol | IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P;RTMP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| User/Host | 20 (Total bandwidth: 160 M.) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage | FTP; Micro SD card (256 G); NAS; SFTP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Browser | IE: IE9 and later
Chrome: Chrome 42 and later Firefox: Firefox 48.0.2 and later |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Management Software | Smart PSS; DSS; DMSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Mobile Phone | IOS, Android | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Certifications | CE-LVD: EN62368-1,EN60950-22 (optional) CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07,UL 50E NEMA Type 4X (optional) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| RS-485 | 1 (Bit rate: 1200 bps-115200 bps) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Input | Audio Interface: 1/1 channel In/Out | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Audio Output | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Input | 3 channel In: 5mA 5V DC
2 channel Out: 1000mA 30V DC/500mA 50V AC |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Output | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Supply | 12V DC/24V AC/PoE+ (802.3at); ePoE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power Consumption | Basic power consumption: 5.4W (12V DC); 5W(24V AC); 4.9W (PoE)
Max. power consumption (Max. stream + intelligent function + IR LED + focus): 16.7W (12V DC);15.7W(24V AC); 15.6W (PoE) Heat power consumption: 3.3W (12V DC);5.5W(24V AC); 5.5W (PoE) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Environment |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Operating Conditions | –40°C to +60°C (–40°F to +140°F)/Less than 95% RH | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage conditions | –40°C to +60°C (–40°F to +140°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Protection Grade | IP67, IK10, Anti-Corrosion Protection: NEMA 4X (optional) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Structure |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Casing | Metal + Plastic | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions | 129.1 mm × Φ157.9 mm (5.08″ × Φ6.22″) (L × W × H) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gross Weight | 1600 g (3.53 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Net Weight | 1500 g (3.31 lb) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
