V3600G1-C V-SOL 8 Port XG(S) Combo PON OLT (AC+DC 48V) + SFP XG/XGS Combo SFP
Rp69.414.283
Model: V1600GS-O32
Spec: 1*GPON with 1×32 splitter 2*RJ45+1*SFP/SFP+
Weight: 2.41kg
Deskripsi
Specifications
| tem | V3600G1-C | |
| Chassis | Rack | 1U 19Inch Standard Box |
| Uplink Port | QTY | 8 |
| RJ45(GE) | 1 | |
| SFP28(25GE) | 4 | |
| QSFP28(25GE/50GE/100GE) | 2 | |
| XG(S)-PON/GPON Port | QTY | 8 |
| Physical Interface | SFP+ Slots | |
| Connector Type | XG(S)-PON&GPON Combo mode: N2_C+ | |
| Single GPON mode: Class B+/C/C+/C++/C+++/C++++ | ||
| Optical Splitting Ratio | 1:256(Maximum), 1:128(Recommended) | |
| Management Ports | 1*10/100/1000BASE-T out-band port,
1*CONSOLE port, 1*USB3.0, 1*Type-C USB console, 1*MicroSD port |
|
| Backplane Bandwidth (Gbps) | 1960 | |
| Port Forwarding Rate(Mpps) | 566.928 | |
| XG(S)-PON&GPON Combo Port Specification | Transmission Distance | 20KM |
| XG(S)-PON Port Speed | GPON:Upstream1.244Gbps,Downstream 2.488Gbps
XG-PON: Upstream 2.488Gbps, Downstream 9.953Gbps XGS-PON: Upstream 9.953Gbps, Downstream 9.953Gbps |
|
| Wavelength | GPON:Upstream 1310nm, Downstream 1490nm
XG(S)-PON:Upstream: 1270nm Downstream: 1577nm |
|
| Supported PON ports | PON 1~8 (8 PON ports are in XG(S)-PON&GPON Combo mode by default ) | |
| GPON Port Specification | Transmission Distance | 20KM |
| GPON Port Speed | Upstream: 1.244Gbps,Downstream: 2.488Gbps | |
| Wavelength | Upstream: 1310nm, Downstream: 1490nm | |
| Supported PON ports | PON 1~8 (Each PON port can be manually hot-switch to GPON mode) | |
| Lightning Protection | Power Lightning Protection | 6KV |
| Interface Lightning Protection | 4KV | |
| Power Supply | AC | Working Voltage Range: 100~240V,
Rated Voltage: 110V/220V |
| Number of Fans | 4 | |
| Management Mode | CLI(Console/Telnet/SSH)/WEB/SNMP | |
